Specifications
| GPU Architecture | NVIDIA Grace Blackwell, NVIDIA Blackwell Architecture |
| CPU Cores | 20, 20-core Arm processor (10 Cortex-X925 + 10 Cortex-A725) |
| Storage Interface | 1 TB or 4 TB NVMe M.2 with self-encryption, NVMe M.2 |
| Storage Capacity | 1 TB, 4 TB |
| GPU Processor | NVIDIA GB10 Grace Blackwell Superchip |
| CUDA Cores | NVIDIA Blackwell Generation |
| Tensor Cores | 5th Generation |
| Ray Tracing Cores | 4th Generation |
| Memory Interface | 256-bit |
| Memory Bandwidth | 273 GB/s |
| NVENC | 1x |
| NVDEC | 1x |
| Display Connectors | 1x HDMI 2.1a; Up to 3x DisplayPort over USB-C (DP Alt Mode) |
| Form Factor | Small form factor (SFF) |
| Dimensions | 150 mm L x 150 mm W x 50.5 mm H |
| Weight | 1.2 kg |
| Memory Type | LPDDR5x |
| Memory Speed | 4266 MHz |
| USB Internal Headers | 4x USB Type-C |
| Operating Temperature | 5°C to 30°C (41°F to 86°F) |
| Operating Humidity | 10% to 90% (non-condensing) |
| Power Supply | 240 Watts |
| TF32 Tensor Core Performance | Up to 1 PFLOP FP4 |
| Supported Operating Systems | NVIDIA DGX OS |
| Storage Over Ethernet | 1x RJ-45 connector 10 GbE |
| NIC/DPU Slots | ConnectX-7 Smart NIC @ 200 Gbps |
| FP4 Tensor Core Performance | Up to 1 PFLOP (with sparsity) |
| AI Compute Performance | Up to 1,000 TOPS (trillion operations per second) inference; Up to 1 PFLOP at FP4 precision with sparsity |
| CPU Architecture | Arm (10 Cortex-X925 + 10 Cortex-A725) |
| System Memory | 128 GB LPDDR5x, coherent unified system memory |
| AI Model Support | Up to 200 billion parameters (single system); Up to 405 billion parameters (dual-Spark configuration); Up to 700 billion parameters (four-Spark configuration) |
| Storage Encryption | Self-encryption |
| Wi-Fi | WiFi 7 |
| Bluetooth | BT 5.4 |
| Audio-output | HDMI multichannel audio output |
| Video Processing | 1x NVENC; 1x NVDEC |
| GB10 TDP | 140 W |
| Copy Engines | 2 |
| Interconnect Technology | NVIDIA NVLink-C2C (CPU+GPU coherent memory model with 5x the bandwidth of PCIe Gen 5) |
| Multi-System Clustering | Up to 4 NVIDIA DGX Spark systems via ConnectX-7 networking |
| Pre-installed Software | NVIDIA AI software stack |
