Specifications
| CPU Support | AMD EPYC 7003 (with AMD 3D V-Cache Technology), AMD EPYC 7002 Series, AMD EPYC 7001 Series |
| Memory Type | DDR4 RDIMM, NVDIMM-N, DDR4 LRDIMM, DDR4 RDIMM/LRDIMM-3DS |
| LAN Controller | Realtek RTL8211E, Intel X550-AT2 |
| Form Factor | ATX |
| Socket Count | 1 |
| Maximum TDP Support | 225W |
| Dimensions | 12" x 9.6" (30.5 cm x 24.4 cm) |
| Rated Voltage | 1.2V |
| Socket Type | Socket SP3 (LGA 4094) |
| Chipset | System on Chip |
| Memory Channels | 8 |
| Number of Memory Slots | 8 |
| Memory Speed | RDIMM: up to 3200MHz; LRDIMM: up to 3200MHz; NVDIMM-N: up to 2666MHz |
| LAN Ports | 2x RJ45 10GbE by Intel X550-AT2; 1x RJ45 Dedicated IPMI LAN port by RTL8211E |
| Onboard Graphics | ASPEED AST2500 |
| PCIe Expansion Slots | SLOT7 (closest to CPU): PCIe 4.0 x16; SLOT6: PCIe 4.0 x16; SLOT5: PCIe 4.0 x16; SLOT4: PCIe 4.0 x16; SLOT3: PCIe 4.0 x16; SLOT2: PCIe 4.0 x16 (shared with M.2/OCuLink/SATA by jumper); SLOT1: PCIe 4.0 x16 |
| M.2 Slots | 2x M.2 (2230/2242/2260/2280/22110) PCIe 4.0 x4 or SATA 6Gb/s |
| Storage Interface | 10x SATA3 6.0 Gb/s (9x from 2x mini SAS HD and 1x SATA DOM port); 2x M.2 (PCIe 4.0 x4 or SATA 6Gb/s); 2x OCuLink (PCIe 4.0 x4) |
| Power Connectors | 1x 24-pin ATX main power connector; 2x 8-pin ATX 12V power connectors; 1x 4-pin ATX 12V power connector |
| USB Internal Headers | 1x USB 3.2 Gen1 x2 header; 1x USB Type-C header |
| Rear USB Ports | 2x USB 3.2 Gen1; 1x USB Type-C Gen2 |
| TPM | 1x TPM 2.0 17-pin Header |
| BMC | ASPEED AST2500 |
| Maximum Memory Capacity | RDIMM: up to 512GB (64GB per DIMM); LRDIMM: up to 1024GB (128GB per DIMM); RDIMM/LRDIMM-3DS: up to 2048GB (256GB per DIMM); NVDIMM-N: up to 256GB (32GB per DIMM) |
| Remote Management | IPMI |
| Video Output | VGA; Mini-DP |
| Dedicated Video Memory | 512 MB DDR4 SDRAM |
| BIOS Type | AMI |
| BIOS Features | ACPI 2.0 support; IPMI support; SMBIOS 2.8 support |
| Hardware Features | WatchDog Timer; Dual LAN Teaming; Energy Efficient Ethernet 802.3az; Preboot eXecution Environment (PXE) |
