Specifications
| Form Factor | SSI EEB (12" x 13"), 4U Rackmount |
| Compatible Drive Type | SATA, SAS |
| Dimensions | 699.0 x 432.0 x 176.0 mm (27.52" x 17.01" x 6.93") |
| Weight | 42.0 kg |
| PCIe Expansion Slots | 6 x Low Profile |
| Rear USB Ports | 2x USB 3.0 |
| Front Panel Header | Power On/Off; Alarm Mute; System Reset; 2x USB 3.0 |
| 80 PLUS Efficiency | Platinum |
| Power Supply | 1+1 Redundant CRPS 1200W 80 PLUS Platinum |
| Number of Drives | 36 |
| Drive Bay | 36 x 3.5" Hot-swap |
| Support Drive Size | 2.5"/3.5" |
| Support Hot-Swap | Yes |
| Storage Backplane | 6Gb/s mini-SAS with expander on-board; 12Gbps SAS expander IC on backplane |
| Cooling System | Middle: 6 x 80mm (T=38mm), PWM, Hot-swap; Rear: 2 x 40mm (Option) |
| Metal Thickness | 1.2mm |
