Power Consumption
|
At Duty Cycle 50%: 3.84 W,
At Duty Cycle 0~ 20%: 1.20 W,
At Duty Cycle 100%: 22.8 W
|
|
CPU Socket
|
LGA115x,
LGA1366,
LGA1700,
LGA1851,
LGA2011/2066 Square ILM,
AM2/AM3/AM4/AM5/FM1/FM2
|
|
Maximum TDP Support
|
Intel: 300 W,
AMD: 205 W
|
|
Fan Speed
|
At Duty Cycle 0~20%: 1350 ± 200 RPM,
At Duty Cycle 50%: 3100 ± 10% RPM,
At Duty Cycle 100%: 6000 ± 5% RPM
|
|
Air Flow
|
At Duty Cycle 0~ 20%: 23.085 CFM,
At Duty Cycle 50%: 53.01 CFM,
At Duty Cycle 100%: 102.60 CFM
|
|
Noise Level
|
At Duty Cycle 0~ 20%: 24.77 dBA,
At Duty Cycle 50%: 42.82 dBA,
At Duty Cycle 100%: 57.16 dBA
|
|
Static Pressure
|
At Duty Cycle 0~ 20%: 1.152 mm-H2O,
At Duty Cycle 50%: 6.074 mm-H2O,
At Duty Cycle 100%: 22.752 mm-H2O
|
|
Lead Wire Pin Out
|
Pin1- (-),
Pin2- (+),
Pin4- (PWM),
Pin3- (Tachometer/Signal output)
|
|
Form Factor
|
2U Server and up
|
|
CPU Support
|
Intel & AMD
|
|
Fan Dimension
|
80 x 80 x 38 mm
|
|
Bearing Type
|
2 Ball Bearing
|
|
Rated Voltage
|
12V
|
|
Fan Life Expectancy
|
70,000 Hours
|
|
Screw Type
|
#6-32/M3/M4
|
|
Installation Torque
|
6-10 in-lb/5-7 in-lb/10-16 in-lb
|
|
Cold Plate Dimension
|
64.5 x 64.5 x 23 mm
|
|
Radiator Dimension
|
383.5 x 86.5 x 85.4 mm
|
|
Thermal Compound
|
Shin-Etsu 7762 or Equivalent
|
|
Water Pump Flow Rate
|
2.9 Liter Per Minute
|
|
Tube Length
|
300 mm
|
|
Tube Material
|
Black EPDM
|
|
Number of Fans
|
4
|
