Power Consumption
|
At Duty Cycle 0~20%: 0.60 W,
At Duty Cycle 50%: 3.84 W,
At Duty Cycle 100%: 19.2 W
|
|
Fan Speed
|
At Duty Cycle 0~20%: 1000±200 RPM,
At Duty Cycle 50%: 3500±10% RPM,
At Duty Cycle 100%: 7000 RPM
|
|
Air Flow
|
At Duty Cycle 0~20%: 6.5 CFM,
At Duty Cycle 50%: 11.2 CFM,
At Duty Cycle 100%: 22.28 CFM
|
|
Noise Level
|
At Duty Cycle 0~20%: 21.5 dBA,
At Duty Cycle 50%: 43.0 dBA,
At Duty Cycle 100%: 59.14 dBA
|
|
Static Pressure
|
At Duty Cycle 0~20%: 2.27 mm-H2O,
At Duty Cycle 50%: 18.56 mm-H2O,
At Duty Cycle 100%: 74.18 mm-H2O
|
|
Lead Wire Pin Out
|
Pin1-Black (-),
Pin2-Yellow (+),
Pin3-Green (Tachometer/Signal output),
Pin4-Blue (PWM)
|
|
Power Connector
|
4-pin PWM
|
|
Form Factor
|
1U Server
|
|
CPU Socket
|
LGA 1851/1700
|
|
CPU Support
|
Intel Core 12th-15th Gen
|
|
Maximum TDP Support
|
125W
|
|
Heatsink Material
|
Copper Heatsink with Skiving Fins
|
|
Dimensions
|
92.0 x 90.0 x 28 mm
|
|
Weight
|
444 ± 5 g
|
|
Fan Dimension
|
Ø80.0 x 15.0 mm
|
|
Bearing Type
|
Double Ball
|
|
Rated Voltage
|
12V
|
|
Fan Life Expectancy
|
70000 Hours (continuous operating at 40°C)
|
|
Screw Type
|
M3
|
|
Installation Torque
|
5-7 in-lb
|
