Fan Speed
|
At Duty Cycle 0~20%: 2400±10% RPM,
At Duty Cycle 50%: 4800±10% RPM,
At Duty Cycle 100%: 8000±5% RPM
|
|
Air Flow
|
At Duty Cycle 0~20%: 35.52 CFM,
At Duty Cycle 50%: 67.24 CFM,
At Duty Cycle 100%: 115.61 CFM
|
|
Power Connector
|
4-pin PWM
|
|
Form Factor
|
2U Server
|
|
CPU Socket
|
SP5
|
|
CPU Support
|
AMD Genoa Processor Family
|
|
Maximum TDP Support
|
700W
|
|
Heatsink Material
|
Copper base
|
|
Fan Dimension
|
80.0 x 80.0 x 38 mm
|
|
Bearing Type
|
Double Ball
|
|
Rated Voltage
|
12V
|
|
Screw Type
|
M3.5
|
|
Installation Torque
|
12.5-15.1 in-lb
|
|
Cold Plate Dimension
|
118 x 92.4 x 24.8 mm
|
|
Radiator Dimension
|
304.9 x 82 x 85.1 mm
|
|
Pump Power Consumption
|
4.8W
|
|
Thermal Compound
|
Shin-Etsu 8195 or Equivalent Pre-Printed
|
|
Water Pump Flow Rate
|
2.9 Liter Per Minute
|
|
Tube Length
|
300 mm
|
|
Tube Material
|
Black Pair EPDM
|
|
Number of Fans
|
3
|
