Specifications
| CPU Socket | Intel LGA1851, Intel LGA1700, Intel LGA1200, Intel LGA115X, AMD AM5, AMD AM4 |
| Power Consumption | At Duty Cycle 0~20%: 0.2 W, at Duty Cycle 50%: 0.5 W, at Duty Cycle 100%: 1.6 W |
| Form Factor | 1.5U & Up |
| Maximum TDP Support | Intel: 135 W; AMD: 130 W |
| Heatsink Material | Copper Base & Aluminum Fins with Heat Pipe embedded |
| Dimensions | 93.4 x 95.0 x 35.2 mm |
| Weight | 392g (Fan + Heatsink) |
| Fan Dimension | 92.0 x 92.0 x 12.0 mm |
| Fan Speed | At Duty Cycle 0~20%: 800 ± 200 RPM, at Duty Cycle 50%: 1900 ± 10% RPM, at Duty Cycle 100%: 3200 ± 10% RPM |
| Bearing Type | Double Ball |
| Rated Voltage | 12V |
| Air Flow | At Duty Cycle 0~20%: 9.88 CFM, at Duty Cycle 50%: 21.38 CFM, at Duty Cycle 100%: 35.78 CFM |
| Noise Level | At Duty Cycle 0~20%: 22.3 dBA, at Duty Cycle 50%: 26.1 dBA, at Duty Cycle 100%: 36.2 dBA |
| Static Pressure | At Duty Cycle 0~20%: 0.28 mm-H2O, at Duty Cycle 50%: 1.22 mm-H2O, at Duty Cycle 100%: 3.21 mm-H2O |
| Lead Wire Pin Out | Pin#1- Black(-), Pin#2- Black (+), Pin#3- Black (Tachometer/ Signal Output), Pin#4- Black (PWM) |
| Fan Life Expectancy | 70,000 Hours |
| Screw Type | #6-32/M3 |
| Installation Torque | 6-10 in-lb/5-7 in-lb |
| Thermal Compound | Shin-Etsu 7762 or Equivalent |
